CS-6 IW Master Pack

CS-6 IWMP
Find a Reseller
In stock
PhaseTech 6" 2-way In-Wall Speaker Master Pack (12 Units)

PhaseTech CS-6 Ceiling Speaker Master Pack (12 Units)

The perfect complement to CS in-ceiling speakers, the CS-6 iW brings the same high-performance and features usually found in much more expensive speakers. value as the rest of the CS line to an in-wall design. With a 12 dB/oct crossover metal binding posts, high-powered .75 inch variable-axis tweeter and a 6.5 inch Poly woofer, the CS-6 iW is the easy answer for high-quality in-wall audio at an entry level price. Featuring a magnetic, micro-flange grille, the CS-6 iW looks just as good as it sounds.

Owner's Manual

About PhaseTech
More Information
ColorWhite
UPC644216207206
ManufacturerPhase Technology
Manufacturer's CategoryCS Professional Series
Depth3.75 in / 95.25 mm
Height12.37 in / 314.3 mm
Width/Diameter8.5 in / 215.9 mm
Shipping Weight60.5 lbs / 27.44 kg
Carton Height15.75 in / 400.05 mm
Carton Length27.75 in / 704.85 mm
Carton Width19.75 in / 501.65 mm
Enclosure PropertiesInfinite Baffle
Included AccessoriesGrille, Hole Template
Optional AccessoriesPre-Construction Bracket (RB25)
Source InputsMetal Push Binding Posts
Cutout Width/Diameter6.6 in / 167.64 mm | 8.06 in / 204.8 mm
Frequency Response (± 3 dB)50 Hz - 20 kHz
Grille PropertiesFlangeless, Magnetic, Powder-Coated, White, Paintable
Mounting Depth3.4 in / 86.36 mm
Nominal Impedance (Ω Ohms)8 Ω
Tweeter Driver.75" Variable Axis Soft Dome
Woofer Driver6.5" Coaxial Polypropylene w/ NBR Surround
Recommended Power5-100 W
Sensitivity dB @ 2.83V/1M87 dB
