Mighty Mite 43-BGM (Black)
MM43-BGM-BK
In stock
Now Shipping!
SoundTube Mighty Mite 4-inch, 3-way Hanging Speaker in Silver<br>
<h3>SoundTube Mighty Mite 3-Way Hanging Speaker</h3>
<h4 style="color:#40b3cd; line-height:29px;">
From the creator of The Original Pendant Speaker™ in 1996, SoundTube Entertainment has just reinvented the category with the launch of the Mighty Mite. The UL-approved and patented Mighty Mite is the only full-range pendant speaker with a built-in subwoofer eliminating the need to install a separate subwoofer and subwoofer amplifier. Mighty Mite’s redefined aesthetics give designers options for the pendant category they haven’t seen before. The sleek ultra-modern look and feel fits comfortably in any décor where design is as essential as sound quality.
</h4><br>
<p>
The MM43-BGM is a 3-way pendant speaker with a 5.25” dual-chamber, band-pass subwoofer, a 4” woofer and a .75” BroadBeam® ring tweeter, with high-frequency dispersion technology for wide off-axis coverage. <b>Mighty Mite’s</b> subwoofer with phase-aligned bass produces even, full-range coverage, smooth response, and loud, clean sound from one point of origin. With its built-in subwoofer and expansive coverage over larger areas than conventional pendant speakers, the <b>Mighty Mite</b> generates exceptional sound for music and voice applications. In addition, the speaker’s wide coverage capabilities mean fewer speakers are needed thus further reducing both hardware and labor costs for the project.<br><br>
<br>
<img src="https://mseaudio-site-files.s3.us-west-2.amazonaws.com/MightyMite_productpage_1.jpg" alt="Mighty Mite Features">
<br><br>
Ideal for paging, background music, foreground music and most open-ceiling applications, the <b>Mighty Mites</b> have a built-in 30-Watt transformer for standard 25/70/100-volt applications or can be used as direct 8-ohm speakers. The unique driver combination gives unprecedented phase-matched audio between the low, mid, and high frequencies.<br><br>
<b>Mighty Mite</b> has an integrated hanging bracket at the top of the speaker and comes with UL-listed hanging hardware with cables and integrated SpeedClamp™ self-locking wire grip for fast, easy, and secure installation. The MM43-BGM is 22” high with a 7.4” diameter, weigh 14 lbs.<br><br>
</p>
<p><a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/MM_Owners_Manual.pdf" target="_blank">Owner's Manual</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/Mighty+Mite+Tech+Sheet_MM43-BGM-Preliminary.pdf" target="_blank">Tech Sheet</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/Mighty_Mite_Mechanical.png" target="_blank">Mechanical Drawing</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/MM43-BGM.DWG" target="_blank">DWG</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/MM43-BGM.rfa" target="_blank">Revit</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/MM43-BGM.pdf" target="_blank">PDF Drawing</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/MightyMite_cutsheet.pdf" target="_blank"> Cut Sheet</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/MM43-BGM.gll" target="_blank" data-rel="fancybox">GLL</a> |
<a href="https://mseaudio-soundtube-downloads.s3.us-west-2.amazonaws.com/MM43-BGM+AE.pdf" target="_blank">A&E Specs </a>
</p>
<br>
<a href="https://soundtube.mseaudio.com/SoundTube" class="btn btn-default" style="background-color:#40B3CD;color:#fff;font-family:'helvetica';font-size:16px;letter-spacing:0.05em;font-weight:400;">About SoundTube</a>
Color | Black |
---|---|
UPC | 644216231706 |
Manufacturer | SoundTube |
Manufacturer's Category | MM/DS Contemporary Pendants |
Height | 21.9 in / 556 mm |
Width/Diameter | 7.4 in / 188 mm |
Shipping Weight | 13.15 lbs. / 5.96 kg |
Certifications | CE, RoHS, UL1480, UL2239 |
Enclosure Properties | ABS |
Included Accessories | Hanging Hardware, Terminal Weather Boot |
Source Inputs | 4 Pin Ceramic Terminal |
TAA Compliant (Trade America) | No |
BAA Compliant (Made in USA) | No |
Crossover Frequency | 100 Hz; 2.5 kHz |
Frequency Response (± 10 dB) | 37 Hz - 27 kHz |
Frequency Response (± 3 dB) | 62 Hz - 24 kHz |
Grille Properties | Magnetic, Powder-Coated |
Max. Continuous Power RMS | 30 W |
Max SPL @ 1M | 103 dB |
Max. Program Power | 60 W |
Nominal Impedance (Ω Ohms) | 8 Ω |
Tweeter Driver | .75" Synthetic Soft Dome |
Woofer Driver | 4" Polypropylene Cone with Butyl Rubber Surround |
Subwoofer Driver | 5.25" Polypropylene Cone w/ Rubber Surround |
Sensitivity dB @ 1W/1M | 84 dB |
Sensitivity dB @ 2.83V/1M | 84 dB |
Tap Selector | Rotary Switch |
Transformer Options | Included 70.7 / 100 V transformer (30 W maximum) |
